Phaser 6128MFP Service Manual 10-11
Wiring
Denotes the control and its outline in the
Board.
Denotes a connection between parts with
harness or wires, attached with signal name/
contents.
Denotes the function, and logic value of the
signal to operate the function (Low: L, High:
H).
The given voltage is for signal in high status.
The arrow indicates the direction of signal.
Denotes the function, and logic value of the
signal when the function operated (Low: L,
High: H).
The given voltage is for signal in high status.
The arrow indicates the direction of signal.
Denotes a connection between wires.
Denotes a Clutch or Solenoid.
Denotes a Motor.
Symbol Description
Control
s6128mfp-162
DEVE_A
s6128mfp-163
CLUTCH ON(L)+24V
s6128mfp-164
EXIT SENSED(L)+3.3VDC
s6128mfp-165
s6128mfp-166
s6128mfp-167
M
s6128mfp-168
