Xerox Phaser 6128MFP Service Manual

Phaser 6128MFP Service Manual A-9
Reference
MM Millimeters
MOT Motor
MPT Multi-Purpose Tray
NCS Non-Contact Sensor
NVM Non-Volatile Memory
NVRAM Non-Volatile Random Access Memory
OHP Overhead Paper (Transparency)
OPT Optional
OS Operating System
PCB Printed Circuit Board
PCL Printer Command Language
PDL Page Description Language
P/J Plug Jack (electrical connections)
PJL Printer Job Language
PL Parts List
POP3 Post Office Protocol version 3
PPD PostScript Printer Description
PPM Pages Per Minute
PWBA Printed Wiring Board Assembly
RAM Random Access Memory
RH Relative Humidity
RMS Root Mean Square Voltage
ROM Read-Only Memory
ROS Raster Output Scanner - Laser Unit
SEF Short-Edge Feed
SMB Server Message Block
SNMP Simple Network Management Protocol
SNR Sensor
SOL Solenoid
SOS Start of Scan
TDC Toner Density Control
TNR Toner
UI User Interface
USB Universal Serial Bus
WINS Wireless Integrated Network Sensor
Acronym Description

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
