Parameter Value
Input signal range -24 V DC +24 V DC 24 V AC 50/60 Hz
Signal 0 -5 V...+3 V -3 V...+5 V 0 V AC...5 V AC
Undefined signal -15 V...-5 V +5 V...+15 V 5 V AC...14 V AC
Signal 1 -30 V...-15 V +15 V...+30 V 14 V AC...27 V AC
Input current per channel
Input voltage 24 V Typ. 5 mA Typ. 5 mA r.m.s.
Input voltage 5 V Typ. 1 mA Typ. 1 mA r.m.s.
Input voltage 14 V Typ. 2.7 mA r.m.s.
Input voltage 15 V > 2.5 mA
Input voltage 27 V Typ. 5.5 mA r.m.s.
Input voltage 30 V < 8 mA
Max. permissible leakage current (at
2-wire proximity switches)
1 mA Typ. 1 mA r.m.s.
Input delay (0->1 or 1->0) Typ. 8 ms
Input data length 1 byte
Max. cable length
Shielded 500 m
Unshielded 300 m
1
) When inputs are used with 24 V AC, external surge limiting filters are required.
Ordering data
Part no. Description Product life cycle phase *)
1TNE 968 902 R2101 DI561, digital input module, 8 DI,
24 V DC / 24 V AC
Active
1TNE 968 901 R3101 Terminal block TA563-9, 9 pins, screw
front, cable side, 6 pieces per unit
Active
1TNE 968 901 R3103 Terminal block TA564-9, 9 pins, screw
front, cable front, 6 pieces per unit
Active
1TNE 968 901 R3105 Terminal block TA565-9, 9 pins, spring
front, cable front, 6 pieces per unit
Active
*) Modules in lifecycle Classic are available from stock but not recommended
for planning and commissioning of new installations.
1.6.1.1.4 DI562 - Digital input module
● 16 digital inputs 24 V DC / 24 V AC (I0 to I15) in 2 groups
● Group-wise galvanically isolated
Device specifications
