Parameter Value
Demagnetization with inductive DC load A free-wheeling diode must be circuited in par-
allel to the inductive load
Switching frequency
With resistive load Max. 10 Hz
With inductive load Max. 2 Hz
With lamp load On request
Max. cable length
Shielded 1000 m
Unshielded 600 m
Ordering data
Part no. Description Product life cycle phase *)
1SAP 245 000 R0001 DX531, digital input/output module,
8 DI, 230 V AC, 4 DO relays, 2-wires
Active
*) Modules in lifecycle Classic are available from stock but not recommended
for planning and commissioning of new installations.
1.6.1.2.9 Fast counter
More information can be found in the Automation Builder chapter, “Fast counters in AC500
devices”.
1.6.2 Analog I/O modules
1.6.2.1 S500-eCo
1.6.2.1.1 AI561 - Analog input module
● 4 configurable analog inputs (I0 to I3) in 1 group
● Resolution: 11 bits plus sign or 12 bits
Device specifications
