ABB AC500 V3 - Technical data of the relay outputs

Parameter Value
Input delay (0->1 or 1->0) Typ. 8 ms, configurable from 0.1 to 32 ms
Input signal voltage 24 V DC
Signal 0 -3 V...+5 V
Undefined signal > +5 V...< +15 V
Signal 1 +15 V...+30 V
Ripple with signal 0 Within -3 V...+5 V
Ripple with signal 1 Within +15 V...+30 V
Input current per channel
Input voltage +24 V Typ. 5 mA
Input voltage +5 V > 1 mA
Input voltage +15 V > 5 mA
Input voltage +30 V < 8 mA
Max. cable length
Shielded 1000 m
Unshielded 600 m
Technical data of the relay outputs
Parameter Value
Number of channels per module 8 relay outputs
Distribution of channels into groups 8 groups of 1 channel each
Connection of the channel R0 Terminal 2.0 (common), 3.0 (NO) and 4.0 (NC)
Connection of the channel R1 Terminal 2.1 (common), 3.1 (NO) and 4.1 (NC)
Connection of the channel R6 Terminal 2.6 (common), 3.6 (NO) and 4.6 (NC)
Connection of the channel R7 Terminal 2.7 (common), 3.7 (NO) and 4.7 (NC)
Galvanic isolation Between the channels and from the rest of the module
Indication of the output signals One yellow LED per channel, the LED is ON when the
relay coil is energized
Monitoring point of output indicator LED is controlled by process CPU
Way of operation Non-latching type
Output delay (0->1 or 1->0) On request
Relay power supply By UP process supply voltage
Relay outputs
Output short circuit protection Should be provided externally with a fuse or circuit
breaker
Rated protection fuse 6 A gL/gG per channel
Min. switching current 10 mA
Output switching capacity
Resistive load, max. 3 A; 3 A (230 V AC), 2 A (24 V DC)
Inductive load, max. 1.5 A; 1.5 A (230 V AC), 1.5 A (24 V DC)
Lamp load 60 W (230 V AC), 10 W (24 V DC)
