ABB AC500 V3 - 1.8.2 AC500 (standard); 1.8.2.1 MC502 - Memory card

Table 182: Technical data of the module
Parameter Value
Process supply voltage
Connections Terminal (L+) for +24 V DC and terminal (M) for
0 V DC
Rated value 24 V DC
Max. ripple 5 %
Protection against reversed voltage Yes
Galvanic isolation Yes (on processor module PM50xx)
Isolated Groups 1 (6 channels per group)
Weight 18 g
Mounting position Horizontal or vertical
Table 183: Technical data of the inputs
Parameter Value
Number of channels per module 6 digital input channels (+24 V DC)
Distribution of the channels into groups 1 (6 channels per group)
Connections of channels I0 to I5 Terminals 2...7
Reference potential for the channels I0 to I5 Terminal 1 (negative pole of the process supply
voltage, signal name C0...5)
Input current per active channel (at input
voltage +24 V DC)
The current is given through the used pro-
cessor module.
Typ. 5 mA
Inrush current per active channel
The current is given through the used pro-
cessor module.
Typ. 5 mA
Part no. Description Product life cycle phase *)
1SAP 187 600 R0001 TA5400-SIM, input simulator
for PM50x2
Active
*) Modules in lifecycle Classic are available from stock but not recommended
for planning and commissioning of new installations.
1.8.2 AC500 (standard)
1.8.2.1 MC502 - Memory card
● Solid state flash memory storage
Ordering data
Device specifications
Accessories > AC500 (standard)
2022/01/313ADR010278, 3, en_US884
