ABB AC500 V3 - 1.7.2.3.10 Technical data; Technical data of the digital inputs

LED Color OFF ON Flashing
S-ERR Red No error Internal error --
I/O bus Green No decentralized
I/O modules con-
nected or com-
munication error
Decentralized I/O
modules con-
nected and
operational
---
LED Color OFF ON Flashing
DC0 to DC7 Yellow Input/output is OFF Input/output is ON --
DI8 to DI15 Yellow Input is OFF Input is ON (the input
voltage is even dis-
played if the supply
voltage is OFF)
--
DO8 to DO15 Yellow Output is OFF Output is ON --
UP Green Process supply
voltage missing
Process supply
voltage OK and initi-
alization finished
--
UP3 Green Process supply
voltage missing
Process supply
voltage OK
--
CH-ERR1 to
CH-ERR3
Red No error or process
supply voltage
missing
Internal error Error on one channel
of the corresponding
group
1.7.2.3.10 Technical data
The system data of AC500 and S500 Ä Chapter 2.6.1 “System data AC500” on page 971 are
applicable to the standard version.
The system data of AC500-XC
Ä Chapter 2.7.1 “System data AC500-XC” on page 1023 are
applicable to the XC version.
Only additional details are therefore documented below.
The technical data are also applicable to the XC version.
Multiple overloads
No effects of multiple overloads on isolated multi-channel modules occur, as
every channel is protected individually by an internal smart high-side switch.
Technical data of the digital inputs
Parameter Value
Number of channels per module 8
Distribution of the channels into groups 1 group of 8 channels
Terminals of the channels DI0 to DI7 Terminals 3.0 to 3.7
Reference potential for all inputs Terminals 2.9 ... 4.9 (negative pole of the
supply voltage, signal name ZP)
States of the 29
process LEDs
