Autonics GP Series User Manual

125
10.3 OBJECT SELECTION, MOVEMENT AND SIZE
ADJUSTMENT
10.3.1 Select an object
It is able to change clicked or included object in a drag area into selecting status. In this case,
it is able to designate selection target.
Selection target
Press
Release
Select only figure object.
Release
Press
Select only tag.
Press
Press
Select all objects.
Release
Release
It is not able to select any object.
(1)Click the object with left button of mouse, it is changed into selected status. Selected object
displays mark to adjust size as following figure.
(2)Pressing left button of mouse and drag it, dotted rectangle is created. The object included in a
rectangle is changed as selected status when taking off from a mouse.
Selected object
