31.4 GP INNER DEVICE
●System information (UW0~UW29) : When configuring device in system information of editor, these
devices and GP inner device UW0~UW29 are share same value.
UW area Read area Write area
UW0 Screen number displaying of GP
UW1 Overlap 1 screen number displaying of GP
UW2 Overlap 2 screen number displaying of GP
UW3 User ID number of input tag
UW4 System signal 2
UW5 System signal 4
UW6 Clock sec
UW7 Clock min
UW8 Clock hour
UW9 Date day
UW10 Date month
UW 11 Date year
UW12 Date day
UW13 Reserved write area
UW14 Reserved write area
UW15 System signal 1
UW16 Current recipe number
UW17 System signal 3
UW18~UW29 Reserved read area
● UW30~UW2047 : It is used as general data register.
● UW2048~UW6047 : It is used as general data register, it is required to notice for using recipe.
UW area Read area Write area
UW30 User area User area
… User area User area
… User area User area
UW2047 User area User area
UW2048
User area (Recipe using area)
…
…
UW6047
