Autonics GP Series User Manual

199
18.3.4 Option tap
Option tap
Definition of key input focus movement
①User ID
•
Designate to configure user ID or not.
②
User ID
•
Designate user ID and it is able to designate within 1~50.
③
Destination
ID
• Designate to configure destination ID or not.
• It is activated when key operation definition is in order of ‘User ID’ in screen auxiliary
configuration.
④
Destination
ID
• Designate destination ID.
⑤Screen
configuration
• Designate input focus movement calling screen auxiliary window.
Focus
movement
of input tag
When pressing ENT after inputting in main device, if key operation definition item in
screen auxiliary configuration is in order of
• ‘User ID’:
Input focus is moved to input tag having destination ID designated in ④.
• ‘No movement’: Input focus is not moved.
•
‘Clear cursor and key window’: Cursor and key window are disappeared.
②
③
①
④
⑤
