Autonics GP Series User Manual

249
27.3 DETAIL CONFIGURATION
27.3.1 Basic tap
Basic tap
Designate type and shape of graph
○
1
•
Bar graph is created when selecting bar.
Graph
○
2
• Designate to use shape.
Shape
•
When checking it, no.1 of memorized shapes is designated as a default.
○
3
• It is activated when
Shape
○
2
•
Pressing a button, select shape calling image selection window.
is checked.
○
4
•
It shows image of current selected shape.
Shape
○
5
• Designate frame color.
Frame
•
It is activated when shape is specified.
○
6
• Designate plate color.
Plate
•
It is activated when shape is specified.
①
② ③
④
⑤
⑥
