200

19. TIME DISPLAY

It displays time or date using a clock of inner GP regardless of controller (PLC) connected with GP.

19.1 BASIC OPERATION

▣ Date display

▣ Date display type

Display type

Date type

①

Date

YY/MM/DD

②

Date

DD/MM/YY

③

Date

MM/DD/YY

④

Date

DD/MM/YYYY(DAY)

⑤

Date

DD/MM/YYYY

▣ Time display

▣ Time display type

Display type

Time type

①

Time

24H(HH:MM:SS)

②

Time

24H(HH:MM)

③

Time

12H(HH:MM:SS)

④

Time

12H(HH:MM)

03/1/13

13/1/03

1/13/03

03/1/13

13/JAN/2003(MON)

13/JAN/2003

①

②

③

④

⑤

⑥

20:55

20:55:36

①

②

③

④

10:55 PM

10:55:36 PM
