Autonics GP Series User Manual

18
1.4 THE RATING
Model
GP-2480
Power supply
24VDC ±10%
Power consumption
3.6W max
Noise strength
The square wave noise (Pulse width 1㎲) by the noise simulator
with ±1000V R/S phase and repetition frequency 60Hz
Dielectric strength
500VAC(50/60Hz) for a minute
Insulation resistance
Min. 100MΩ (at 500VDC)
Ground
3
rd
grounding (Max. 100Ω)
Vibration
Mechanical
0.75mm amplitude at frequency of 10~55Hz (for a minute) in
each of X, Y, Z directions for an hour
Malfunction
0.5mm amplitude at frequency of 10~55Hz (for a minute) in each
of X, Y, Z directions for 10 minutes
Ambient temperature
0℃ ~ 50℃(at non-freezing status)
Storage temperature
-20℃ ~ 60℃(at non-freezing status)
Ambient humidity
35% ~ 85% RH (at non-dew status)
Protection structure
IP 65F for front panel
Unit weight
Approx. 300g
Model
GP-S057
Power supply
24VDC ±10%
Power consumption
3.6W max
Noise strength
The square wave noise (Pulse width 1㎲) by the noise simulator
with ±500V R/S phase and repetition frequency 60Hz
Dielectric strength
500VAC(50/60Hz) for a minute
Insulation resistance
Min. 100MΩ (at 500VDC)
Ground
3
rd
grounding (Max. 100Ω)
Vibration
Mechanical
0.75mm amplitude at frequency of 10~55Hz (for a minute) in
each of X, Y, Z directions for an hour
Malfunction
0.5mm amplitude at frequency of 10~55Hz (for a minute) in each
of X, Y, Z directions for 10 minutes
Ambient temperature
0℃ ~ 50℃(at non-freezing status)
Storage temperature
-20℃ ~ 60℃(at non-freezing status)
Ambient humidity
35% ~ 85% RH (at non-dew status)
Protection structure
IP 65F for front panel
Unit weight
Approx. 400g
Model
LP-S044
