3.5.5 Configuration/access key
It is used to check the position of key for moving from user screens to system screens or re-configure.
Number Function and operation
It is set as configuration/access key position.
It is not set as configuration/access key.
It can be configured up to max. 2 configuration/access keys. In this case, pressing 2
position keys simultaneously, it is moved to system configuration screens.
※Notice
• When editing the screen with vertical direction, the default position of configuration/access key for
designed data is in the upper left. (The bottom part of the screen is faced to the left side.)
• When inputting power during touch the point of the upper left, it is available to return to the
system screen.
• If there are numeric input/ASCII input/touch key tag on the position of configuration/access
key, tags are only operated and it is not moved to the system screens.
