Autonics GP Series User Manual

81
7.3.4 Configuration of serial port
It is configuration of serial connection when connecting main device with editor, barcode reader and
print.
It is configuration of port, not CH1 communication port, in system screen [Channel connection] of GP.
In case of GP-2480-SBD0 and RS422 A PORT is using for CH1, it configures to connect editor,
barcode reader, print with RS232C B PORT.
When using editor, printer, barcode, CH2, the object should be designated as the appropriate
equipment connecting to port not connected with CH1 in [SERIAL PORT] in system screen of GP.
Configuration
item
Settable value
Speed
300, 600, 900, 1200, 2400, 4800, 9600, 19200, 38400, 57600bps
Handshaking
XON/XOFF, DSR/DTR
Parity
None, Even, Odd
Data bit
7, 8 bit
Stop bit
1, 2 bit
