Autonics GP Series - Page 217

217
(2) Cursor OFF (FFA5h)
(3) Cursor UP (FFABh)
(4) Cursor DOWN (FFACh)
Occurred Message
02/12/04 10:10:12 M0 ON
02/12/04 10:14:43 M2 ON
Cursor on
Press touch key configured
as FFA5h.
It does not choose any
row.
Occurred Message
02/12/04 10:10:12 M0 ON
02/12/04 10:14:43 M2 ON
Cursor off
Cursor on
Cursor off
Occurred Message
02/12/04 10:10:12 M0 ON
02/12/04 10:14:43 M2 ON
Cursor Up
Press touch key configured
as FFA6h.
The upper one is
selected
status.
Occurred Message
02/12/04 10:10:12 M0 ON
02/12/04 10:14:43 M2 ON
Cur Down
Cursor Up
Cur Down
Occurred Message
02/12/04 10:10:12 M0 ON
02/12/04 10:14:43 M2 ON
02/12/04 10:25:07 M5 ON
Cursor Up
Pres
s touch key configured
as FFA7h.
The lower one is
selected
status.
Occurred Message
02/12/04 10:10:12 M0 ON
02/12/04 10:14:43 M2 ON
02/12/04 10:25:07 M5 ON
Cur Down
Cursor Up
Cur Down
