297

Write trigger

Configuration of write trigger

①② device

•

Designate bit device for write trigger.

③ trigger

•ON: It executes write operation at the moment designated device is changed

as ON status.

•OFF: It executes write operation when designated device is changed as OFF

status.

※Notice

Read trigger is optional, but write trigger is essential.

Default Chapter6
