309

Time action Configuration of each time action

①,②,③

• Hour/Min/Sec of start time occurring the action

④ ~ ⑩

• Check the day occurring the action

⑪,⑫,⑬

• Hour/Min/Sec of end time of the action

Action tap configures bit device related with action, it is able to designated lead

device for the first item only. It ON the appropriated bit device at the moment of

start time in checked day and OFF at end time.
