D-Link DWL-2600AP User Manual

Configuring and Viewing Device Port Information
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 107
D-Link UWS User Manual
Configuring and Viewing Device Port Information
The pages in the Port folder allow you to view and monitor the physical port information for the ports available
on the switch.
Port Configuration
Use the Port Configuration page to configure the physical interfaces on the switch.
To access the Port Configuration page, click LAN > Administration > Port Configuration > Port Configuration
in the navigation tree.
Figure 38: Port Configuration

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
