D-Link DWL-2600AP User Manual

RADIUS Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 418
D-Link UWS User Manual
Viewing Named Accounting Server Status
The RADIUS Named Accounting Server Status page shows summary information about the accounting servers
configured on the system.
Figure 288: RADIUS Named Accounting Server Status
Click Refresh to update the page with the most current information.
Table 246: Named Accounting Server Fields
Field Description
RADIUS Accounting Server
Name
Shows the RADIUS accounting server name.
Multiple RADIUS accounting servers can have the same name. In this case,
RADIUS clients can use RADIUS servers with the same name as backups for
each other.
IP Address Shows the IP address of the RADIUS server.
Port Number Identifies the authentication port the server uses to verify the RADIUS server
authentication. The port is a UDP port.
Secret Configured Indicates whether the shared secret for this server has been configured.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
