Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 449
D-Link UWS User Manual
Command Buttons
The page includes the following buttons:
• Refresh—Updates the page with the latest information.
• Clear Statistics—Reset all counters on the page to zero.
Viewing Switch Status and Statistics Information
The Switch Status/Statistics page for each switch provides information about the access points it manages and
their associated clients. If the switch is the Cluster Controller, it provides the switch status and statics
information about each switch in its group.
Use the drop-down menu to select the switch with the information to display. If the local switch is the only
available option, then it is the only switch in the cluster, or it is not a Cluster Controller.
TSPEC Statistics (Voice and Video)
Total TSPEC Packets
Received
The number of TSPEC packets sent from the wireless client to the AP. The number is
a total for all APs managed by the switch.
Total TSPEC Packets
Transmitted
The number of TSPEC packets sent from the AP to the wireless client. The number is
a total for all APs managed by the switch.
Total TSPEC Bytes
Received
The number of TSPEC bytes sent from the wireless client to the AP. The number is a
total for all APs managed by the switch.
Total TSPEC Bytes
Transmitted
The number of TSPEC bytes sent from the AP to the wireless client. The number is a
total for all APs managed by the switch.
Total TSPECs Accepted The number of TSPEC packets that were accepted by all APs that the switch manages.
Total TSPECs Rejected The number of TSPEC packets that were rejected by all APs that the switch manages.
Total Roaming TSPECs
Accepted
The total number of TSPEC packets transmitted by roaming clients that were
accepted by all APs that the switch manages.
Total Roaming TSPECs
Rejected
The total number of TSPEC packets transmitted by roaming clients that were
rejected by all APs that the switch manages.
Note: Only the Cluster Controller switch can display managed APs, clients, statistics, and RF Scan
database information for the whole cluster. The switches that are not Cluster Controllers can display
information about locally attached devices.
Table 258: Global WLAN Status/Statistics (Cont.)
Field Description

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
