D-Link DWL-2600AP User Manual

Managing the DHCP Server
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 137
D-Link UWS User Manual
Reset Configuration
Use the Reset Configuration page to clear IP address bindings between that the DHCP server assigned to the
client.
To access the Reset Configuration page, click LAN > Administration > DHCP Server > Reset Configuration in
the navigation tree.
Figure 59: Reset Configuration
• After you select the bindings or conflicts to clear and, if necessary, enter the specific IP address, click Clear
to remove the binding from the DHCP server.
Table 51: Reset Configuration Fields
Field Description
Clear Specifies what to clear from the DHCP server database:
• All Dynamic Bindings: Deletes all dynamic bindings from all address pools.
• Specific Dynamic Binding: Deletes the specified binding.
• All Address Conflicts: Deletes all address conflicts from the DHCP server
database.
• Specific Address Conflict: Deletes a specified conflicting address from the
database.
Clear IP Address If you select Specific Dynamic Bindings or Specific Address Conflicts from the
Clear field, the screen refreshes and the Clear IP Address field appears. Enter
the specific IP address to clear from the DHCP server.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
