D-Link DWL-2600AP User Manual

Locating WLAN Devices
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 651
D-Link UWS User Manual
Figure 408: Building
The following table shows the fields available on the Building page.
Command Buttons
The page includes the following buttons:
• Delete— Deletes the selected building from the database.
• Delete All—Deletes all buildings configured in the database.
• Refresh—Updates the page with the latest information.
Table 374: Building
Field Description
Building Number Unique number from 1–8 that identifies a building within the wireless
system.
Building Description A description for the building, such as an address or function. The
name can be up to 64 characters. The default name is Building-n,
where n is the building number.
Total Floor Count Number of floors configured for the building.
Total AP Count Number of APs in the building with an administratively-configured
physical location.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
