Viewing System Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 168
D-Link UWS User Manual
Port Summary Statistics
The Port Summary Statistics page shows a summary of per-port traffic statistics on the switch. To access the
Port Summary Statistics page, click LAN > Monitoring > System Statistics > Port Summary.
Figure 81: Port Summary
• Click Clear Counters to clear all the counters. This resets all statistics for this port to the default values.
• Click Clear All Counters to clear all the counters for all ports on the switch. The button resets all statistics
for all ports to default values.
• Click Refresh to refresh the data on the screen and display the most current statistics.
Table 73: Port Summary Statistics Fields
Field Description
Interface Use the drop-down menu to select the interface for which data is to be displayed or
configured.
ifIndex This field indicates the ifIndex of the interface table entry associated with this port
on an adapter.
Total Packets Received
Without Errors
The total number of packets received that were without errors.
Packets Received With
Error
The number of inbound packets that contained errors preventing them from being
deliverable to a higher-layer protocol.
Broadcast Packets
Received
The total number of good packets received that were directed to the broadcast
address. Note that this does not include multicast packets.
Packets Transmitted
Without Errors
The number of frames that have been transmitted by this port to its segment.
Transmit Packet Errors The number of outbound packets that could not be transmitted because of errors.
Collision Frames The best estimate of the total number of collisions on this Ethernet segment.
Time Since Counters
Last Cleared
The elapsed time, in days, hours, minutes, and seconds since the statistics for this
port were last cleared.
