D-Link DWL-2600AP User Manual

Locating WLAN Devices
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 652
D-Link UWS User Manual
Building Floor
Use the Building Floor page to define the floors within the buildings where APs are deployed.
Figure 409: Building Floor
The following table shows the fields available on the Building Floor page.
Command Buttons
The page includes the following buttons:
• Delete— Deletes the selected floor from the building.
• Delete All—Deletes all configured floors from the building.
• Refresh—Updates the page with the latest information.
Table 375: Building Floor
Field Description
Building Number Select the number of the building with the floors to define.
Floor Number Unique number from 1–20 that identifies the floor within the selected
building.
Floor Description A description used to identify the floor. The name can be up to 64
characters. The default description is None.
Total AP Count Number of APs on the floor with an administratively-configured
physical location.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
