D-Link DWL-2600AP User Manual

Loopback Interfaces
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 303
D-Link UWS User Manual
Loopbacks Summary
Use the Loopbacks Summary page to display a summary of configured loopbacks.
To display the page, click LAN > Monitoring > L3 Status > Loopback Summary in the navigation tree.
Figure 193: Loopbacks Summary
• Click Refresh to update the information on the screen.
Table 176: Loopbacks Summary Fields
Field Description
Loopback Interface The ID of the configured loopback interface.
Addresses A list of the addresses configured on the loopback interface.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
