Command Buttons
The page includes the following button:
• Delete All —Manually clear all APs from the All Access Points status page except Managed Access Points.
• Manage — Configure an Authentication Failed AP to be managed by the switch the next time it is
discovered. Select the check box next to the MAC address of the AP before you click Manage You will be
presented with the Valid Access Point Configuration page. You can then configure the AP and click Submit
to save the AP in the local Valid AP database. If you use a RADIUS server for AP validation, you must add
the MAC address of the AP to the AP database on the RADIUS server.
• Acknowledge — Identify an AP as an Acknowledged Rogue. Select the check box next to the MAC address
of the AP before you click Acknowledge. The switch adds the AP to the Valid AP database as an
Acknowledged Rogue.
• Refresh—Updates the page with the latest information.
Managed AP Status
From the WLAN > Monitoring > Access Point > Managed AP Status page, you can access a variety of
information about each AP that the switch manages. The pages you access from the Status tab provide
configuration and association information about managed APs and their neighbors. The pages you access from
the Statistics tab display information about the number of packets and bytes transmitted and received on
various interfaces.
Radio Shows the wireless radio mode the AP is using.
Channel Shows the operating channel for the radio.
Authenticated Clients Shows the number of wireless clients that are associated and authenticated with the
access point per radio.
Note: Some status values for some APs in the All Access Points list are not available. Those are listed
as N/A.
Note: You can sort the list of APs by any of the column heading except for Radio, Channel, and
Authenticated Clients. For example, to sort the APs by the profile they use, click Profile.
Table 268: Monitoring All Access Points (Cont.)
Field Description

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
