D-Link DWL-2600AP User Manual

Managing the DHCP Server
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 139
D-Link UWS User Manual
Server Statistics
Use the DHCP Server Statistics page to view information about the DHCP server bindings and messages.
To access the Server Statistics page, click LAN > Monitoring > DHCP Server Summary > Server Statistics in the
navigation menu.
Figure 61: Server Statistics
Table 53: Server Statistics Fields
Field Description
Automatic Bindings Shows the number of automatic bindings on the DHCP server.
Expired Bindings Shows the number of expired bindings on the DHCP server.
Malformed Messages Shows the number of the malformed messages.
Message Received
DHCPDISCOVER Shows the number of DHCPDISCOVER messages received by the DHCP server.
DHCPREQUEST Shows the number of DHCPREQUEST messages received by the DHCP server.
DHCPDECLINE Shows the number of DHCPDECLINE messages received by the DHCP server.
DHCPRELEASE Shows the number of DHCPRELEASE messages received by the DHCP server.
DHCPINFORM Shows the number of DHCPINFORM messages received by the DHCP server.
DHCPOFFER Shows the number of DHCPOFFER messages sent by the DHCP server.
DHCPACK Shows the number of DHCPACK messages sent by the DHCP server.
DHCPNAK Shows the number of DHCPNAK messages sent by the DHCP server.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
