D-Link DWL-2600AP User Manual

Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 500
D-Link UWS User Manual
Table 293: Detailed Associated Client Status
Field Description
SSID Indicates the network on which the client is connected.
BSSID Indicates the Ethernet MAC address for the managed AP VAP where this client is
associated.
AP MAC Address This field indicates the base AP Ethernet MAC address for the managed AP.
Status Indicates whether or not the client has associated and/or authenticated. The valid
values are:
• Associated: The client is current associated to the managed AP.
• Authenticated: The client is currently associated and authenticated to the
managed AP.
• Disassociated: The client has disassociated from the managed AP, if the client
does not roam to another managed AP within the client roam timeout, it will be
deleted.
Channel Indicates the operating channel for the client association.
User Name Indicates the user name of client that have authenticated via 802.1X. Clients on
networks with other security modes will not have a user name.
Inactive Period This field shows the amount of time since data packets were last received from the
client
Age Indicates the amount of time that has passed since the switch received new status or
statistics updates for this client.
Dot11n Capable Indicates whether the associated client supports the IEEE 802.11n standard.
NetBIOS Name Identifies the NetBIOS name of the wireless client. For Microsoft Windows hosts, the
NetBIOS name is typically the same as, or based on the host name.
Tunnel IP Address This field is blank for all non-tunneled clients. For a tunneled client, this is the
assigned tunnel IP address.
Associating Switch Shows whether the AP that the wireless client is associated to is managed by the
local switch or a peer switch.
Switch MAC Address Shows the MAC address of the switch that manages the AP to which the wireless
client is associated.
Switch IP Address Shows the IP address of the switch that manages the AP to which the wireless client
is associated.
Location The descriptive location configured for the managed AP.
Radio Displays the managed AP radio interface the client is associated to and its configured
mode.
VLAN If client is on a VAP using VLAN data forwarding mode, indicates the current assigned
VLAN.
Transmit Data Rate Indicates the rate at which the client station is currently transmitting data.
Network Time Indicates the amount of time that has passed since this client first authenticated with
the network.
STBC Capable Indicates whether the client is capable of using Space Time Block Coding (STBC). STBC
is an 802.11n technique intended to improve the reliability of data transmissions.
Detected IP Address Identifies the IPv4 address of the client, if available.
Dot11ac Capable Indicates whether the associated client supports the IEEE 802.11ac standard.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
