Configuring Advanced Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 602
D-Link UWS User Manual
Wireless Network List
The wireless network list shows all the wireless networks configured on the switch. The first 16 networks are
created by default. You can modify the default networks, but you cannot delete them. You can add and
configure up to 48 additional networks for a total of 64 wireless networks. Multiple networks can have the
same SSID.
Command Buttons
The page includes the following buttons:
• Add — Add a new network. Enter the SSID in the field below the Wireless Network List, and then click
Add. The Wireless Network Configuration page for the new network appears.
• Refresh—Updates the page with the latest information.
• Delete — Delete a network. Select the check box next to the network ID, and then click Delete. You
cannot delete networks 1–16.
Table 352: Wireless Network List
Field Description
ID Shows an automatically generated unique identifier for the network. IDs up to 16 are
assigned to the 16 networks created by default. The switch supports up to 64
networks.
SSID Identifies the name of the network. The SSID is a hyperlink to the Wireless Network
Configuration page for the network.
VLAN Shows the VLAN ID the wireless network uses.
Hide SSID Shows whether the network broadcasts the SSID. If enabled, the SSID for this
network is not included in AP beacons. To change this setting, click Edit.
L3 Tunnel Shows whether L3 Tunneling is enabled on the network.
Note: When L3 tunneling is enabled, the VLAN ID configured above is not used. In
fact, the switch puts the management VLAN ID, if any, on the tunneled packets
destined to the AP.
Security Shows the current security settings for the network.
Redirect Shows whether HTTP redirect is enabled. The possible values for the field are as
follows:
• HTTP: HTTP Redirect is enabled
• None: HTTP Redirect is disabled
