Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 456
D-Link UWS User Manual
Command Buttons
The page includes the following button:
• Refresh—Updates the page with the latest information.
Viewing the AP Hardware Capability List
The switch can support APs that have different hardware capabilities, such as the supported number of radios,
the supported IEEE 802.11 modes, and the software image required by the AP. From the AP Hardware
Capability tab, you can access summary information about the AP Hardware support, the radios and IEEE
modes supported by the hardware, and the software images that are available for download to the APs.
Figure 307: AP Hardware Capability Information
Configuration Indicates which portions of configuration were last received from a peer switch,
which can be one or more of the following:
• Global
•Discovery
• Channel/Power
• AP Database
• AP Profiles
• Known Client
• Captive Portal
• RADIUS Client
• QoS ACL
• QoS DiffServ
If the switch has not received any configuration for another switch, the value is None.
Timestamp Indicates the last time this switch received any configuration data from a peer
switch.
Table 261: Peer Switch Configuration (Cont.)
Field Description

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
