D-Link DWL-2600AP User Manual

Virtual Router Redundancy Protocol (VRRP)
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 331
D-Link UWS User Manual
• Click Refresh to update the information on the page with the most current data from the switch.
Table 197: Virtual Router Status Fields
Field Description
VRID Virtual Router Identifier.
Slot/Port Indicates the interface associate with the VRID.
Priority The priority value used by the VRRP router in the election for the master
virtual router.
Pre-empt Mode •Enable: If the Virtual Router is a backup router, it preempts the master
router if it has a priority greater than the master virtual router's priority
provided that the master is not the owner of the virtual router IP address.
• Disable: If the Virtual Router is a backup router it does not preempt the
master router even if its priority is greater.
Advertisement Interval(secs) The time, in seconds, between the transmission of advertisement packets by
this virtual router.
Virtual IP Address The IP Address associated with the Virtual Router.
Interface IP Address The actual IP Address associated with the interface used by the Virtual Router.
Owner Set to True if the Virtual IP Address and the Interface IP Address are the same,
otherwise set to False. If this parameter is set to True, the Virtual Router is the
owner of the Virtual IP Address, and always wins an election for master router
when it is active.
VMAC Address The virtual MAC Address associated with the Virtual Router, composed of a
24-bit organizationally unique identifier, the 16-bit constant identifying the
VRRP address block and the 8-bit VRID. The Virtual MAC address is:
00:00:5e:00:01:XX,
where XX is the VRID.
Auth Type The type of authentication in use for the Virtual Router
• None: Specifies that the authentication type is none.
• Simple: Specifies that the authentication type is a simple text password.
State The current state of the Virtual Router:
• Initialize
• Master
• Backup
Status The current status of the Virtual Router:
• Inactive
• Active
Secondary IP Address A secondary VRRP address configured for the primary VRRP.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
