Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 480
D-Link UWS User Manual
Command Buttons
The page includes the following button:
• Refresh—Updates the page with the latest information.
Viewing Managed Access Point Ethernet Statistics
The Ethernet summary statistics show information about the number of packets and bytes transmitted and
received on the wired interface of each access point managed by the switch. The wired interface is physically
connected to the LAN.
Table 280 describes the fields you see on the Ethernet Summary page for the managed access point statistics.
Viewing Detailed Managed Access Point Statistics
The detailed AP statistics show information about the packets and bytes transmitted and received on the
wired and wireless interface of a particular access point managed by the switch. To view statistics for a specific
AP that the switch manages, select its MAC address from the drop-down menu above the table. The location,
if available, is also displayed with the MAC address.
Table 281 describes the fields you see on the Detail page for the managed access point statistics.
Note: You can sort the list of APs by clicking any of the column headings. For example, to sort the APs
by the number of packets transmitted, click Packets Transmitted.
Table 280: Managed Access Point Ethernet Summary Statistics
Field Description
MAC Address The Ethernet address of the DWS-4000 Series switch-managed AP.
Packets Received Total packets received by the AP on the wired network.
Bytes Received Total bytes received by the AP on the wired network.
Packets Transmitted Total packets transmitted by the AP on the wired network.
Bytes Transmitted Total bytes transmitted by the AP on the wired network.
Table 281: Detailed Managed Access Point Statistics
Field Description
WLAN Packets Received Total packets received by the AP on the wireless network.
WLAN Bytes Received Total bytes received by the AP on the wireless network.
WLAN Packets Transmitted Total packets transmitted by the AP on the wireless network.
WLAN Bytes Transmitted Total bytes transmitted by the AP on the wireless network.
WLAN Packets Receive Dropped Number of packets received by the AP on the wireless network that
were dropped.
