D-Link DWL-2600AP User Manual

Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 530
D-Link UWS User Manual
Viewing the RRM Channel Load History
The RRM Channel Load History page shows the last 100 channel load history entries. If a new entry is added
when the list is full then the oldest entry is purged.
Figure 349: RRM Channel Load History
The following table describes the fields on the RRM Channel Load History page.
Command Buttons
The page includes the following buttons:
• Delete All—Remove all entries from the list.
• Refresh—Updates the page with the latest information.
Table 317: RRM Channel Load History
Field Description
Client MAC Address MAC Address of the client that reported the channel load measurement.
Channel Channel on which the client measured utilization.
Duration How long the client measured the channel. The value is in time units (TUs). for which
to measure the channel. Each TU is equal to 1024
μs.
Channel Load Measured Channel Load. The value is reported in terms of percentage utilization.
Age Time since this measurement was reported.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
