Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 483
D-Link UWS User Manual
Command Buttons
The page includes the following button:
• Refresh—Updates the page with the latest information.
Viewing Managed Access Point VAP Statistics
The VAP statistics show information about the client failures and number of packets and bytes transmitted and
received on each VAP on radio one or two for a particular access point managed by the switch.
Use the options above the table to select the AP, radio, and VAP with the settings to view. The AP is identified
by its MAC address and location. The radio is identified by its number and configured mode. If the radio is
disabled, the radio mode will be displayed as Off. The VAP is identified by the VAP ID and its SSID. All VAPs are
available regardless of whether they are enabled.
Table 283 describes the fields you see on the VAP page for the managed access point statistics.
Frames Transmitted Count of each successfully transmitted MSDU.
WEP Undecryptable Count Count of encrypted frames received and the key configuration of the
transmitter indicates that the frame should not have been encrypted or
that frame was discarded due to the receiving station not implementing
the privacy option.
TSPEC Statistics (Voice and Video)
Total TSPEC Packets Received The number of TSPEC packets sent from the wireless client to the AP on
the radio.
Total TSPEC Packets Transmitted The number of TSPEC packets sent from the AP to the wireless client on
the radio.
Total TSPEC Bytes Received The number of TSPEC bytes sent from the wireless client to the AP on the
radio.
Total TSPEC Bytes Transmitted The number of TSPEC bytes sent from the AP to the wireless client on the
radio.
Table 283: Managed Access Point VAP Statistics
Field Description
WLAN Packets Received Total packets received by the AP on this VAP.
WLAN Bytes Received Total bytes received by the AP on this VAP.
WLAN Packets Transmitted Total packets transmitted by the AP on this VAP.
WLAN Bytes Transmitted Total bytes transmitted by the AP on this VAP.
WLAN Packets Receive Dropped Number of packets received by the AP on this VAP that were dropped.
WLAN Bytes Receive Dropped Number of bytes received by the AP on this VAP that were dropped.
WLAN Packets Transmit Dropped Number of packets transmitted by the AP on this VAP that were dropped.
WLAN Bytes Transmit Dropped Number of bytes transmitted by the AP on this VAP that were dropped.
Table 282: Managed Access Point Radio Statistics
Field Description
