Telnet Sessions
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 92
D-Link UWS User Manual
Removing or Modifying a Port Mirroring Session
1. From the Port Mirroring page, click Remove Source Port.
2. Select one or more source ports to remove from the session.
Use the CTRL key to select multiple ports to remove.
3. Click Remove.
The source ports are removed from the port mirroring session, and the device is updated.
Telnet Sessions
Telnet is a terminal emulation TCP/IP protocol. ASCII terminals can be virtually connected to the local device
through a TCP/IP protocol network. Telnet is an alternative to a local login terminal where a remote login is
required.
The switch supports up to five simultaneous telnet sessions. All CLI commands can be used over a telnet
session.
The Telnet Session Configuration page allows you to control inbound telnet settings on the switch. Inbound
telnet sessions originate on a remote system and allow a user on that system to connect to the switch CLI. To
configure outbound telnet settings, which are telnet sessions that originate on the switch to access a remote
system, see “Outbound Telnet Client Configuration” on page 94.
To display the Telnet Session Configuration page, click LAN > Administration > Telnet Session in the navigation
tree.
Figure 26: Telnet Session Configuration

Table of Contents

Other manuals for D-Link DWL-2600AP

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DWL-2600AP and is the answer not in the manual?

D-Link DWL-2600AP Specifications

General IconGeneral
Networking standardsIEEE 802.3af
Ethernet LAN data rates10, 100 Mbit/s
Maximum data transfer rate300 Mbit/s
InternalYes
LED indicatorsPower, Stand-by, Status, WAN, WLAN
WAN connectionEthernet (RJ-45)
Ethernet LAN (RJ-45) ports1
Security algorithmsWEP, WPA, WPA2
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Width160 mm
Height45 mm
Weight240 g
Dimensions (WxDxH)160 x 160 x 45 mm
