D-Link DWL-2600AP User Manual

Configuring Port Security
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 378
D-Link UWS User Manual
Port Security Violation Status
Use the Port Security Violation Status page to enable or disable the port security feature on your switch.
To access the Port Security Violation Status page, click LAN > Monitoring > Port Security > Port Security
Violation in the navigation tree.
Figure 255: Port Security Violation Status
Table 220: Port Security Violation Status Fields
Field Description
Interface Select the physical interface or the LAG on which to view security violation
information.
Last Violation MAC Address Displays the source MAC address of the last packet that was discarded at a
locked port.
VLAN ID Displays the VLAN ID corresponding to the Last Violation MAC address.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
