D-Link DWL-2600AP User Manual

MAC Access Control Lists
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 366
D-Link UWS User Manual
MAC ACL Rule Configuration
Use the MAC ACL Rule Configuration page to define rules for MAC-based ACLs. The access list definition
includes rules that specify whether traffic matching the criteria is forwarded normally or discarded. A default
'deny all' rule is the last rule of every list.
To display the MAC ACL Rule Configuration page, click LAN > QoS > Access Control Lists > MAC Access Control
Lists > Rule Configuration in the navigation menu.
The fields available on the page depend on whether the rule action is permit or deny, and whether you select
Create Rule or an existing rule from the Rule field.
Figure 245 shows the fields available when Create New Rule is selected in the Rule field.
Figure 245: MAC ACL Rule Configuration (Create Rule)
Figure 246 shows the fields available when you configure a MAC ACL rule with a Deny action.
Figure 246: MAC ACL Rule Configuration (Deny Action)

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
