Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 507
D-Link UWS User Manual
Command Buttons
The page includes the following button:
Refresh—Updates the page with the latest information.
Viewing Associated Client SSID Status
Each managed AP can have up to 16 different networks that each have a unique SSID. Although several
wireless clients might be connected to the same physical AP, they might not connect by using the same SSID.
The WLAN > Monitoring > Client > Associated Clients > SSID Status page lists the SSIDs of the networks that
each wireless client associated with a managed AP has used for WLAN access.
To disconnect a client from an AP, select the box next to the SSID, and then click Disassociate.
Figure 331: SSID Associated Client Status
Command Buttons
The page includes the following buttons:
Disassociate—Disassociates the client from the managed AP.
Refresh—Updates the page with the latest information.
RRM Beacon Passive Measurement
Mode
Indicates whether the client supports passive scan capability.
RRM Channel Load Measurement Mode Indicates whether the client supports channel load measurement
Table 299: SSID Associated Client Status
Field Description
SSID Indicates the network on which the client is connected.
Client MAC Address The Ethernet address of the client station.
Table 298: Associated Client RRM Status (Cont.)
Field Description
