Configuring Dynamic ARP Inspection
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 278
D-Link UWS User Manual
DAI ARP ACL Rule Configuration
Use the DAI ARP ACL Rule Configuration page to add or remove DAI ARP ACL Rules.
To display the DAI ARP ACL Rule Configuration page, click LAN > L2 Features>Dynamic ARP Inspection > DAI
ARP ACL Rule Configuration in the navigation tree.
Figure 175: Dynamic ARP Inspection ARP ACL Rule Configuration
Click Add to add a new ARP ACL rule.
Click Submit to delete the entries selected in the Remove column.
Click Refresh to refresh the page with the most current data from the switch.
Table 158: Dynamic ARP Inspection ARP ACL Rule Configuration
Field Description
ARP ACL Name Select the ARP ACL for which information is to be displayed or configured.
Sender IP Address To create a new rule for the selected ARP ACL, enter in this field the Sender IP Address
match value for the ARP ACL.
Sender MAC
Address
To create a new rule for the selected ARP ACL, enter in this field the Sender MAC Address
match value for the ARP ACL.
Remove Use the Remove column to select the particular ARP ACL Rules you want to delete.
