D-Link DWL-2600AP User Manual

Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 506
D-Link UWS User Manual
Command Buttons
The page includes the following button:
• Refresh—Updates the page with the latest information.
Viewing Associated Client RRM Status
The RMM Status page for associated clients contains information about whether a client supports specific
resource radio measurement features defined in the 802.11k specification.
Figure 330: Associated Client RRM Status
Use the menu above the table to select the MAC address of the client with the information to view.
Radio Radio number to which the client is associated.
Roam TS (managed AP only) Indicates whether this traffic stream was established by a roaming client.
Table 298: Associated Client RRM Status
Field Description
RRM Mode Indicates whether this client support 802.11k resource radio
measurement.
RRM Location Mode Indicates whether this client responds to location configuration
requests.
RRM Beacon Table Measurement Mode Indicates whether this client can report detected APs via the
beacon table report.
RRM Beacon Active Measurement Mode Indicates whether the client supports active scan capability.
Table 297: Associated Client TSPEC Status (Cont.)
Field Description

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
