Managing LLDP
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 264
D-Link UWS User Manual
Click Refresh to update the information on the screen with the most current data.
Local Device Summary
Use the LLDP Local Device Summary page to view information about all interfaces on the device that are
enabled to transmit LLDP information.
To display the LLDP Local Device Summary page, click LAN > Monitoring > LLDP Status Local Device
Summary in the navigation tree.
Figure 163: LLDP Local Device Summary
Table 145: LLDP Local Device Information Fields
Field Description
Interface Select from the list of all the ports on which LLDP-802.1AB frames can be
transmitted.
Chassis ID Subtype Displays the string that describes the source of the chassis identifier.
Chassis ID Displays the string value used to identify the chassis component associated
with the local system.
Port ID Subtype Displays the string describing the source of the port identifier.
Port ID Identifies the physical address of the port.
System Name Displays the system name of the local system.
System Description Displays the description of the selected port associated with the local system.
Port Description Displays the user-defined description of the port.
System Capabilities
Supported
Displays the system capabilities of the local system.
System Capabilities Enabled Displays the system capabilities of the local system which are supported and
enabled.
Management Address Displays the advertised management address of the local system.
Management Address Type Specifies the type of the management address.
