D-Link DWL-2600AP User Manual

Router Discovery
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 313
D-Link UWS User Manual
Router Discovery Status
Use the Router Discovery Status page to display Router Discovery data for each port.
To display the page, click LAN > L3 Features > Router Discovery > Status in the navigation tree.
Figure 201: Router Discovery Status
Table 183: Router Discovery Status Fields
Field Description
Interface The router interface for which data is displayed.
Advertise Mode The values are Enable or Disable. Enable denotes that Router Discovery is
enabled on that interface.
Advertise Address The IP Address used to advertise the router.
Maximum Advertise
Interval(secs)
The maximum time (in seconds) allowed between router advertisements
sent from the interface.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
