Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 462
D-Link UWS User Manual
All AP Status
The All AP Status page shows summary information about managed, failed, and rogue access points the switch
has discovered or detected.
Figure 313: All Access Points
The font color for the AP listing indicates that the AP is one of the following types:
• Green—Managed AP
• Orange—Peer Managed AP
• Red—Failed or Rogue AP
• Gray—Unknown AP
To view additional information about the detected AP, click the MAC address of the AP.
Table 268: Monitoring All Access Points
Field Description
MAC Address Shows the MAC address of the access point.
Location A location description for the AP. This is the value configured in the valid AP database
(either locally or on the RADIUS server).
Switch Port The physical port (in the slot/port format) on the switch that the AP is connected to
either directly or indirectly in the same L3 domain. If the AP is beyond the L3 network
boundary, then ‘Unknown’ is displayed.
IP Address The network address of the access point.
Software Version Shows the version of D-Link Access Point software that the AP is running.
Age Shows how much time has passed since the AP was last detected and the information
was last updated.
