Visualizing the Wireless Network
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 676
D-Link UWS User Manual
The following figure identifies the toolbar icons directly below the menu bar.
Figure 429: Toolbar Icons
Locate
Target Access Point Select this option to allow the wireless system to search for an AP and
update its location based on the received search information.
When you select this option, a window opens that allows you to select the
MAC address of the AP to search for and to specify the location search
parameters.
Target Client Select this option to allow the wireless system to search for a client and
update its location based on the received search information.
When you select this option, a window opens that allows you to select the
MAC address of the client to search for and to specify the location search
parameters.
Legend
Images Shows the icons associated with each WLAN component on the graph.
Channel Color Maps the color of the power transmission image to the channel that the
radio is using for transmission.
Help
Help Opens a new HTML window to display the WLAN Visualization online help
page.
Table 386: WLAN Visualization Menu Bar Options (Cont.)
Menu Item Description
Live Visualization ControlDefault Image Size
Zoom Out Zoom In Force Refresh
