Viewing System Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 160
D-Link UWS User Manual
• Click Refresh to refresh the data on the screen with the present state of the data in the switch.
• Click Clear Counters to clear all the statistics counters, resetting all switch summary and detailed statistics
to default values. The discarded packets count cannot be cleared.
Switch Summary
Use the Switch Summary page to view a summary of statistics for traffic on the switch.
To access the Switch Summary page, click LAN > Monitoring > System Statistics > Switch Summary in the
navigation tree.
Figure 79: Switch Summary
VLAN Deletes The number of VLANs on this switch that have been created and then deleted
since the last reboot.
Time Since Counters Last
Cleared
The elapsed time, in days, hours, minutes, and seconds, since the statistics for
this switch were last cleared.
Table 71: Switch Summary Fields
Field Description
ifIndex This object indicates the ifIndex of the interface table entry associated with
the Processor of this switch.
Total Packets Received
Without Errors
The total number of packets, including multicast packets, that were directed
to the broadcast address.
Broadcast Packets Received The total number of packets received that were directed to the broadcast
address. Note that this does not include multicast packets.
Table 70: Switch Detailed Statistics Fields (Cont.)
Field Description
