D-Link DWL-2600AP User Manual

Configuring Port Security
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 374
D-Link UWS User Manual
Port Security Administration
Use the Port Security Administration page to enable or disable the port security feature on your switch.
To access the Port Security Administration page, click LAN > Security > Port Security Administration in the
navigation tree.
Figure 251: Port Security Administration
• Select Enable or Disable from the Port Security Mode list and click Submit.
Port Security Interface Configuration
Use this page to configure the port security feature on a selected interface.
To access the Port Security Interface Configuration page, click LAN > Security > Port Security Interface in the
navigation tree.
Figure 252: Port Security Interface Configuration

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
