D-Link DWL-2600AP User Manual

Configuring Advanced Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 595
D-Link UWS User Manual
Table 348 describes the fields on the Wireless Global Configuration page.
Table 348: General Global Configurations
Field Description
Peer Group ID In order to support larger networks, you can configure wireless switches as peers,
with up to 8 switches in a cluster (peer group). Peer switches share some information
about APs and allow L3 roaming among them.
Peers are grouped according to the Group ID.
Client Roam Timeout This value determines how long to keep an entry in the Associated Client Status list
after a client has disassociated. Each entry in the status list shows an age, and when
the age reaches the value you configure in the timeout field, the entry is deleted.
Ad Hoc Client Status
Timeout
This value determines how long to keep an entry in the Ad Hoc Client Status list. Each
entry in the status list shows an age, and when the age reaches the value you
configure in the timeout field, the entry is deleted.
AP Failure Status
Timeout
This value determines how long to keep an entry in the AP Authentication Failure
Status list. Each entry in the status list shows an age, and when the age reaches the
value you configure in the timeout field, the entry is deleted.
MAC Authentication
Mode
Select the global action to take on wireless clients in the
• white-list: Select this option to specify that any wireless clients with MAC
addresses that are specified in the Known Client database, and are not explicitly
denied access, are granted access. If the MAC address is not in the database then
the access to the client is denied.
• black-list: Select this option to specify that any wireless clients with MAC
addresses that are specified in the Known Client database, and are not explicitly
granted access, are denied access. If the MAC address is not in the database then
the access to the client is granted.
MAC Authentication is enabled at the network level. The network configuration also
defines whether MAC addresses are looked up on the local database or on the
RADIUS server.
RF Scan Status Timeout This value determines how long to keep an entry in the RF Scan Status list. Each entry
in the status list shows an age, and when the age reaches the value you configure in
the timeout field, the entry is deleted.
Detected Clients Status
Timeout
This value determines how long to keep an entry in the Detected Client Status list.
Each entry in the status list shows an age, and when the age reaches the value you
configure in the timeout field, the entry is deleted.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
