AutoInstall
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 180
D-Link UWS User Manual
Click Submit to update the switch with the values on the window. Click Refresh to update the information on
the window.
Table 79: AutoInstall Fields
Field Description
AutoInstall Mode Select Start to initiate sending a request to a DHCP server to obtain an IP address of a
server and the configuration file name. If it obtains the server address, AutoInstall
proceeds to search for and download a configuration file from the server. If successful,
it applies the configuration file to the switch. After starting the AutoInstall process, you
can monitor the status of the process by the messages in the AutoInstall State and
Retry Count fields.
Click Stop to end the process.
AutoSave Mode Enable or Disable saving the network configuration to non-volatile memory. When
enabled, the configuration is saved after downloading from the TFTP server without
operator intervention. When disabled, the operator must explicitly save the configuration,
if needed.
Retry Count The number of times the switch has attempted to contact the TFTP server during the
current AutoInstall session.
AutoInstall State The status of the current or most recently completed AutoInstall session.
