Virtual Router Redundancy Protocol (VRRP)
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 328
D-Link UWS User Manual
• Click Add to proceed to the VRRP Interface Tracking page.
• Click Submit to apply the new configuration. Configuration changes take effect immediately. These
changes will not be retained across a power cycle unless a Save configuration is performed.
• Click Refresh to refresh the page with the most current data from the switch.
• Click Cancel to return to the Virtual Router Configuration page.
VRRP Interface Tracking
Use the VRRP Interface Tracking page to add an interface to the tracking list. This page is accessible by clicking
Add from the Virtual Router Configuration page.
Figure 213: VRRP Interface Tracking
• Click Submit to send the updated configuration to the switch. Configuration changes take effect
immediately. These changes will not be retained across a power cycle unless a Save configuration is
performed.
• Click Cancel to return to the VRRP Interface Tracking Configuration page.
Table 194: VRRP Track Interface Fields
Field Description
Slot/Port The interface associated with the Virtual Router ID.
Virtual Router ID The Virtual Router ID for which data is to be displayed.
Track Slot/Port Displays all routing interfaces which are not yet tracked for this Virtual Router
ID and interface configuration. Exceptions to this: loopback and tunnels could
not be tracked.
Priority Decrement The priority decrement for the tracked interface. The valid range is 1-254. The
default value is 10.
